Build More Sustainable Earth Integrated Spaces
This Global DesignTeam offers full services to plan, permit and build your CUSTOM Projects.

All plans are CUSTOM. Just for you. Have you dreamed of creating your own project, but not sure how to start without spending LOTS of money and time figuring out the best way to do this? If so, you are not alone. That's why we have developed a system that is inexpensive, fast, strong and waterproof. Plus, our traveling crews come to your building site any where to construct your custom plan the way you want it.

Typically, within one to two months you have the concrete walls and domed or flat roof built and ready to add doors, windows and complete interiors and landscaping. You can then DIY or hire a local contractor to finish using traditional methods. You may design your own plan, hire your own architect, or use our custom in-house planning service. We have engineering seals in all States for our building systems and have assisted with permitting in other countries when required.
This site offers information, plans and photographs of earth-sheltered homes, underground construction and wine caves. We provide cost estimates for your project in each state of the USA and abroad once your custom plans are completed.

How to get started:

All of our structures are custom designed to fit individual customer needs as well as the building site itself. When we receive information from you about the project that you plan to create, we will be able to speak in detail about the possibilities and choices  for your project that typically offer planning and building services below market value.

CONTACT us by email with more questions at buildearthshelter@gmail.com and we can schedule a free phone consultation.

RECEIVE  FREE 4 hours of planning time to get you started on your CUSTOM PROJECT:

winery plan

Services Offered: Planning, Modeling, Rendering, Drafting, Details, Specifications, Scheduling, Estimating...

tasting room
tasting room
press to zoom
Floor Plan sample
Floor Plan sample
press to zoom
vineyard tastingroom
vineyard tastingroom
press to zoom
Two bedroom w steel garage
Two bedroom w steel garage
press to zoom
interior
interior
press to zoom
farmhouse plan
farmhouse plan
press to zoom
TIR aerial
TIR aerial
press to zoom
cabin plan
cabin plan
press to zoom
Architecture Model Sketching
Architecture Model Sketching
press to zoom
Rendering
Rendering
press to zoom
Hammond House Pool copy_edited
Hammond House Pool copy_edited
press to zoom
Wine Tasting
Wine Tasting
press to zoom
1/2

What Construction Documents and Building Permit Application Regulations are Required to Build Your Project?



Building in the US & MOST COUNTRIES have many building permit requirements, INCLUDING:

  • Dimensioned site plans showing property features and boundaries

  • Dimensioned Floor Plans of each Floor

  • Exterior and Interior Elevations

  • Sections with Structural Details - Walls, Ceilings, Doors, Stairs, Foundations, etc

  • Foundations Plan and Footing Details with steel placements and structural calculations

  • Doors and Window Schedules, Sizes and Details

  • Structural System Specifications and detailed attachment specifications.

  •  Fire Security, Fire Truck Road access inspections and approvals,  Sprinkler Systems and water pressure and storage calculations

  • Site planning during construction: repelling water, drainage, waste disposal, construction materials storage, soil storage, etc.

  • Sound Proofing Specification and Installation Details when required

  • Heating, Cooling and Ventilation plan and systems specifications

  • Electrical Plan with compliant outdoor lighting fixtures

  •  Plumbing Plan with compliant installation details

  • Structural details and Calculations with Engineering seals

  •  Green Review Compliance Checklist

  • Installation, Use calculations, Code Compliance and Maintenance of Power, Dehumidification, Filtering, Venting, Air Circulation and Energy Systems

  • Water Storage, Water Filtration, Septic and Grey Water Systems

  • Parking and Outdoor Lighting Plans and Specifications



This team provides building construction, permitting and regulations drawings  from small to large projects. We know how to comply with the building regulations. Online Architecture Services does exactly what you want at affordable prices.



Floor Plans - Floor plans are types of drawings that show the layout of a property from above. Some people call it a bird’s eye view. These floor plans typically show what a building looks like by illustrating the location of walls, windows, doors, stairs, and other fixed installations. A floor Plan makes it easier to understand the space in an easy way.

Custom Earth Sheltered Construction's Building Process & Advantages  for Wine Cave, Resorts, Schools, Homes, etc.

With enormous environmental & economical benefits, there are many reasons to construct Wine / Cheese Caves & Earth Sheltered or Green Roof structures for your business. It is the Ultimate “Green” Build.

Wine Caves and Earth Sheltered Buildings utilize the earth’s insulation properties to reduce energy costs. When compared to the energy usage required to cool and heat above ground buildings, the savings is substantial. And imagine how the hillsides look without more surface buildings. When building underground from 2000 sf or 30,000 sf. land and resources are saved by building with our concrete form building system.

Earth Cover maximizes Temperature and Humidity to acti as a virtual air conditioner during the summer and radiant heater to connected buildings in the winter, wine caves provide relatively constant temperature and humidity, averaging 55-65 degrees year round. Wine caves and Earth Sheltered buildings provide reduced impact land, energy and water use, developing more profits while being more environmentally responsible. Many residents and environmentalists oppose above ground structures that destroy the natural landscape and cause irreversible damage to forests and hillsides. Wine caves typically receive favorable support from counties involved in the wine industry.



Cost Efficiency - Our improvements in construction technology have allowed caves and underground building to remain cost competitive, often competitive with surface construction costs. This is not typical of most systems who typically cost more. Grapes and other plantings are easily grow on top after construction, maximizing land use while saving heating, cooling and water costs in production.



Long Life, Low Maintenance and Extreme Weather Security - Our improve construction methods integrated with earth sheltered and underground applications   brings many advantages. These concrete structures are made to last for generations with minimal upkeep. Our 30+ years of experience has included building many earth sheltered buildings from wine caves to schools that have withstood extreme weather conditions including tornados, hurricanes, earthquakes and floods.



Wine Caves and Earth Sheltered Hotels & Homes Attract Customers - There is a romance about a cave that is difficult to describe. Experience shows that wine caves as destination attract additional visitors when besides storage and processing facilities, they are also used as tasting rooms, reception halls and other public events. The facilities can remain rustic, with a natural feel or become sleek and modern depending on the owner's style tastes.

Increased Marketing Potential - As the wine and tourism industries become more competitive, constructing a cave allows owners to extend their winery's brand and generate more enthusiasm and word of mouth referrals. Caves are now used extensively during wine auction weekends, marketing events, philanthropic benefits, and other events held for worldwide distributors.

The Custom Earth Sheltered Wine Cave Building Process: Cave Works and Earth Sheltered Construction encompasses a range of services and techniques including:

  • Excavation for the poured-in-place monolithic concrete modular caves and earth sheltered and above ground buildings with domed ceilings. The placement choices below the ground are extensive with some being places several feet below the ground to being bermed over at ground level and above ground buildings with green roof gardens. During the planning process the owners desires are addressed and the caves are placed accordingly.

  • Installation of the foundations and forming systems according to the owner's design configurations and specifications. Walls and ceilings are reinforced by the insertion of steel reinforcing bars to the highest engineering standard which are customized to each unique cave building.

  • Allowances for basic utilities and ventilation are placed in walls and ceilings before the concrete is poured including – hot and cold water, compressed air, gas, cables, internet, electrical, HVAC, drainage, etc. as required by owner.

  • A pump truck is accompanied by the concrete trucks during the pouring process into the aluminum form sets. It only requires typically two to three hours to pour the concrete into the forming system which when complete is 650 to 1000 sf each plus retaining walls as required.

  • After the forms are removed from the concrete to be set up for the next section the sections cure a few days before waterproofing, interior and exterior finishing, mechanical systems, etc. are completed.

  • These concrete buildings are later covered with soil using earth moving equipment. The strength of domed formed ceiling allows extensive soil to be placed on top which can be planted as the owner wishes.

We share our years of experience planning and building earth sheltered caves, homes, schools, businesses, etc. to insure the owners' create their dream project in the manner they wish with consideration to aesthetics, time and budget. You are the primary designer throughout the process as we provide the support and coordination required to build your wine cave or other earth sheltered and green roof project.

Your vision for the form and function of your wine cave and earth sheltered project is unique. We guide you through this process from the overall layout, portal configurations, doors, lighting, ventilation, wash stations, plumbing, finishes, floors, drainage, waterproofing, barrel storage methods, aesthetics, ventilation, intersections, architectural style, dimensions, entertainment areas, etc. More planning upfront will result in a project that proceeds efficiently and avoids delays and additional costs. Our team is honored to serve and assist in all the capacities required to build your dream project.

CONTACT us by email with more questions at buildearthshelter@gmail.com and we can schedule a free phone consultation.

CUSTOM PLANS AVAILABLE DESIGNED JUST FOR YOU - SEE PRICING & PLANNING >


All types and scales of architecture, design, permitting and construction services are offered. Go here for a Complete List >

Modern dome3.png
Farm Parrking.png
village concept 800_edited.jpg

Site Planning to Interior Design services + all phases between are available...

Italian-Villa-rustic-dining-room_edited.
Southport Rendering_edited.jpg
Gauder plan.png
rroofing details.png

To see more about our team & other projects go to judesteele.wixsite.com/portfolio-resume
